NL-WG2+2.G
- Seats：4 Driving Mileage：>80
- Speed：25 Power System： 48V/5KW AC
- • Model:NL-WG2+2.G
- • Strong powerful 48V/5KW AC Motor
- • Macpherson Independent Suspension
- • Made with High Strength Carbon Steel Integral Frame
- • Accept to do OEM and ODM Order of Best All Electric Cars
- • Hydraulic Double Pipe Brake with Front & Rear Drum Wheel Brake
When and wherever you need 4 seater lifted electric golf cart, welcome to send enquiry to join our team, or learn more about our vehicles.
- Electric-Golf-cart-series-Sichuan-Nuole-Electric-Technology-Co.-Ltd-9ry9hm.pdf Download
- Electric-Golf-cart-series-Sichuan-Nuole-Electric-Technology-Co.-Ltd-9ry9hm.pdf Download
Product Descriptive
Product Details
Product Parts
Product Descriptive
 | STYLISH HEADLIGHTSAs the eye of the golf buggy, the headlights determine the front boy shape and overall outlook dedign. There are many headlight model with DOT standard certificate to choose for your unique golf cart. |
| LCD SCREENLCD touch screen with intelligent functions like linking with bluteeth,phone,listening to music, radio. Customization of special functions supported. |  |
| DRIVER OPERATING TABLEDriver opreatting interface with basic function buttons and upgrades like more certain fucntions, water transfer printing surface are available. | |
| ARMREST WITH CUP HOLDERConsiderate water cup holders on armrest. |  |
 | REAR NON-INDEPENDENT SUSPENSIONThe integral rear axle with spring and hydraulic shock absorption, has the left and right wheel running with small angle change so reduce the tire wear, and lower the height of vehicle body and the center of gravity, so improved the safety and comfort level. |
| DASHBOARDSmart dashboard can display the data you want to monitor like power energy, miles or any others. |  |
 | PREMIUM BOLSTERED HIGH-BACK SEATSHigh-grade rebound pu leather seats with customizable color and deaign, when drive our cengo golf cart, you will feel so good in both supreme comfort and style, also each seat is equipped with DOT standard seat belts, not choose between style and safety, you can enjoy the best of both. |
Product Details
| Key Components | Battery | 6PCSx8V150Ah Lead acid Battery |
| 48V105AH/150AH Lithium Battery | ||
| Motor | 5KW AC motor | |
| Controller | FJ 450A | |
| Performance | Minimum turning radius (m) | 3.2 |
| Climbing ability | 30% | |
| Max. movement after brake at speed of 25km/h | ≤4.5m | |
| Max. loading weight | 360kgs | |
| Net weight | 560kgs | |
| Dimensions | Overall dimensions (mm) | 2885*1230*1910 |
| Standard ground clearance (mm) | 120 | |
| Lifted ground clearance (mm) | 200 | |
| Wheelbase (mm) | 1670 | |
| Front wheel tread (mm) | 890 | |
| Rear wheel tread (mm) | 980 | |
| Container loading Qty | Container loading Qty/20FT | 8 |
| Container loading Qty/40HQ | 21 |
 |
 |
 |
 |
 |
 |
Product Parts
| Optional Accessories | |||
| Lead acid maintenance free battery,6×8V,150Ah | 2 Seats Three-point safety belt | ||
| Lithium battery,48V105Ah | 2+2 Seats& 4Seats Three-point safety belt | ||
| Lithium battery,48V150Ah | 4+2 SeatsThree-point safety belt | ||
| Portable charger for 110V to 220V,48V | 2 Seats&2+2 Seats Integral plastic rain curtain | ||
| On board charger for 110V to 220V,48V | 4 Seats&4+2 Seats Integral plastic rain curtain | ||
| Double A-arm Macpherson independent suspension | 2 Seats Pull out sun blind | ||
| Metal front bumper | 2+2 Seats& 4Seats Pull out sun blind | ||
| Off road tire,23×10-14,aluminum rim(two patterns available) | 4+2 Seats Pull out sun blind | ||
| 2 Seats Seats with two colors | 2 Seats&2+2 Seats Customize the color of the ceiling | ||
| 2+2 Seats& 4Seats Seats with two colors | 4 Seats& 4+2 Seats Customize the color of the ceiling | ||
| 4+2 Seats Seats with two colors | 2 Seats&2+2 Seats Customize the color of the body | ||
| 2 Seats Luxury leather seats(Beige/black optional) | 4 Seats& 4+2 Seats Customize the color of the body | ||
| 2+2 Seats& 4Seats Luxury leather seats(Beige/black optional) | Touch screen combination instrument | ||
| 4+2 Seats Luxury leather seats(Beige/black optional) | |||
